SPD System for service entrances rated up to 250 kW.
Download full SurgePure Mach 2 specifications [pdf]
The SurgePure Mach 2 is designed for commercial/industrial service entrances, IEEE Category B & C Locations, rated up to 250kW. The Mach 2 is also a great choice for downstream panels for a cascading grid of protection.
The Mach 2 SPD System features non-degrading, SE (Single Element for each non-degrading surge-path) surge protection.
The Mach 2 isolates your sensitive downline equipment from nearby switching motor loads and in-house surges as it provides a seamless grid of pure AC power. SurgePure helps preserve your valuable equipment!
- Rated NEMA Type 4X. Indoor/Outdoor, Dust, Drip, Hosedown, Corrosion Proof.
- Type 1 & Type 2, no breaker required / for fast easy panel installations, use 20 amp breaker - CEC RULE 26-420 (2).
- c-ETL-us Listed and Certified to the latest UL 1449, 4th Edition / CSA C22.2 - no. 269, RoHs Compliant.
Optional Remote Aware - set of NO/NC dry contacts for supervisory circuit. Add "RA" after the model number. Contact us to order this feature.
Warranty InformationFull replacement, limited lifetime
Connection Hi-Leg Delta
Max Service Size 250 kW
Enclosure Type CSA (NEMA) Type 4X
